Parker Positioning Cylinder

Parker Positioning Cylinder

We offer a comprehensive range of Parker Position Cylinders that are excellent means of providing multipurpose and affordable monitoring piston position in hydraulic cylinders. Equipped with a switching signal (Read.me Position Switches ) it can be applied to regulate used to control or structure operations which are similar to precise points in a manufacturing process, as permitted by the location of the cylinder's piston. The Parker Read.me switch is an unobtrusive external device, which finds application on steel structured cylinders working at top pressure. These switches are customized to the cylinder and must be indicated at the time of order.

Send Enquiry

ARVI is proud to introduce new generation pneumatic positioning cylinder with the following features.

  • No Extended Piston Rod
  • Conforming to ISO mounting standards
  • Friction Less Bearing
  • Precise calibration with simple SPAN and ZERO adjustments
  • Vibration resistant and Robust Design
  • Aesthetic Look and Feel
  • Reverse acting type available
  • Corrosion resistant with hard chrome plated / aluminium linkages
  • Position transmitter (4 to 20 mA DC)

Control Signal Options:

  • 3 to 15 PSIG
  • 4 to 20 mA
  • HART
  • PROFIBUS

Specifications of EPOS model

Input Signal

4 - 20 mA DC

Impedance

250 + 15 Ω

Supply Pressure

 1.4 to 7 kgf/cm3 (20 to 100 psi)

Air Connection

PT (NPT) 1/4

Gauge Connection

PT (NPT) 1/8

Conduit

PF 1/2 (G1/2)

Protection

IP 66 / IP 65

Ambient Temperature

-20oC to 70oC

Linearity

+ 2% FS

Hysteresis

1% FS

Sensitivity

+ 0.5% FS

Air Consumption

3 LPM (Sup+1.4kgf / cm3 20psi)
